Hebei Changhua Star Vehicle Co., Ltd.

Aluminum Alloy Flammable Liquid Insulated Transport Semi-Trailer

This is a specialized aluminum alloy semi-trailer engineered for transporting flammable liquids such as gasoline and methanol, classified as Class 3 hazmat. Its lightweight aluminum construction reduces tare weight, boosting payload capacity and fuel efficiency while enhancing corrosion resistance. One of its major advantages lies in the use of double-layer insulated, swivel-type storage tanks, which enables excellent temperature maintenance during transportation.

Get A Quote

Aluminum Alloy Flammable Liquid Insulated Transport Semi-Trailer Technical Parameter


Tank trailer information
2King pin50#,90#
3Tank volume(m³)42.85m³(valid volume)
4Overall dimension11700,11900mm*2500,2550mm*3750,3800mm
5Curb weight(kg)7000,6500
6Load capacity(kg)33000,33500


Tank body
6Mediumflammable liquid
7Tank materialaluminium alloy
8Beam materialcarbon steel
10insulation constructionDouble-layer insulation structure

Insulation thickness50mm
10Maximum density of the transported medium770kg/m³
11Compartment number1 unit


Running gear
12Number of axles3
13Tire11R22.5 12PR,12R22.5 12PR
14wheel base5830+1310+1310
15track rear1840/1840/1840
16Tank body protective materialcarbon steel,aluminium alloy
17suspension systemair suspension
