Carbonated Plastic-Lined Trailer

This is a corrosive substance tank semi-trailer manufactured, specifically designed for transporting hydrochloric acid, sodium hydroxide solution, and other Class 8 hazardous liquid chemicals. It is constructed with high-strength steel and features a corrosion-resistant tank body, with side and rear protective devices made of aluminum alloy to handle aggressive media.The plastic-coated inner liner of the tank provides additional protection against corrosion, extends its service life, and ensures a safe transportation process.

Get A Quote

Carbonated Plastic-Lined Trailer Technical Parameter


Tank trailer information
1Product modelHCH9403GFWC
2King pin50#,90#
3Tank volume(m³)28.18m³(valid volume)
4Overall dimension10700mm*2500mm*3650mm
5Curb weight(kg)9000,8500,8200
6Load capacity(kg)31000,31500,31800
Tank body
6MediumHydrochloric acid, sodium hydroxide, corrosive substances
7Tank materialcarbon steel (Internal plastic lining)
8Beam materialcarbon steel
8End coverElliptical head
8Tank structureGoose neck type
10Maximum density of the transported medium1100kg/m³
11Compartment number1 unit
Running gear
12Number of axles3
13Tire11R22.5 12PR,12R22.5 12PR
14wheel base5250+1310+1310
15track rear1840/1840/1840
16Tank body protective materialcarbon steel,aluminium alloy
17suspension systemair suspension
